Small module automatic production line equipment

Name：EVA cutting punching machine

Introduction：

This equipment is designed for the EVA, TPT、PPE、PET etc cutting and punching of solar photovoltaic small modules, which can be compatible with a variety of sizes, simple operation, easy adjustment, suitable for cutting and cutting punching two modes, increase the tail material connection function, simple and fast material exchange.

Details：

Model: YCH-ECC01

Power supply: AC220V 2.5KW

Air supply pressure: 0.6-0.8mpa

Connect the air tube: φ10mm

Machine size: L3000mm*W800mm*H2100MM

Processing range: length 100mm--700mm

Width 80mm--300mm

Thickness 0.2mm--0.5mm

Punching: Shape and size are customized according to the drawing

Cutting accuracy: ±0.2+ (0.2+ L*0.002) mm

Speed: 5--12 pcs /Min

Processing materials: EVA, TPT, PPE, PET or other similar materials
