 Small module automatic production line equipment
Name£ºAutomatic trimming cutting machine
Introduction£º
This machine is designed for the cleaning of excess accessories and debris around the solar photovoltaic panel after lamination, which can be compatible with a variety of small module sizes, and the adjustment of the replacement size controlled by the program is simple and fast, with a high degree of automation, effectively solving the problem that the small module version and size are not easy to be compatible.
Details£º
Device model: YCH-XB01
Device power: AC220V 3.5KW
Air supply pressure: 0.6-0.8mpa
Connect the air tube: ¦Õ10mm
Equipment size:L3000*W1250*H2100mm
Equipment weight: about 1000KG
Processing range: length: 120mm--500mm
         Width:80mm--350mm (other sizes can be customized)
Equipment speed: 4--6 pieces / min
