Name：PV Ribbon High-speed Tinning Machine TS80

Introduction：

The machine is designed for the shaft-mounted product of solar PV copper ribbon .Using import PLC intelligent control system, automatic feeding and discharging.The machine processing speed can reach 100 m/min.With high efficiency, refined precision, low yield strength advantages, now it is the current photovoltaic tinning machine.
§ Employing nondestructive cleaning before tining, it can make more preciser welding and improve the surface’s smoothness;
§ Tin furnace temperature control system is with high precisive and imported heat pipes and platinum resistance, precisely controlling the operating temperature;
§ Independently researching the wind control unit to precisely control the coating required thickness of welding ribbon;
§ Tin solder can be configured automatically add system, making tin face always stay in the use of the standard height, more simple operation , guaranteed quality. .

Details：

Model:TS80

Dimensions:(L)8m*(W)1m*(H)2.5m

Power supply: AC Three-phase 380V 7KW

Processing speed: 60-100M/Min

Production capacity/day:2.7g/m * 80m/min * 60/mim * 22/Hour = 285 KG(Single strip)

Processing strips:1-2PCS
