PV Ribbon Cutting Machine

Name：PV Ribbon Cutting & Bending Machine (C350-SZ)

Introduction：

The machine is developed in order to meet the requirement of customers for the once forming of interconnector cutting and bending (small ‘Z’ type). Controlled by single board computer, the machine can be operated simply and conveniently, cutting and bending can be completed through a complete processing with automatic counting. The bending and cutting size is controlled by the host, and the processing of one to six interconnectors can be conducted at the same time.

Details：

Model: C350-SZ

Power Supply: AC220V 210W

Dimensions: (L) 350 × (W) 250 × (H) 320 (mm)

Weight: 34KG

Processing strips :1-6PCS

Processing materials: Tinned copper strip or other strip-type materials

Cutting length: 1-999.9 mm

Cutting width: 0.8-10.0 mm

Cutting thickness: 0.10-0.60mm

Cutting accuracy: ±(0.2+L×0.002)mm

Count of Cutting : L = 100m, Speed:6 (60PCS/min*6strips)

Cutting error: length error ≤ L × 0.002; perpendicularity error: 0.10 (within 6mm)

Bending Depth: 0.5; bending angle: 0-90° (can be customized).

Information storage: 10 strips
